Malfunctions
Group 30: Electrical system
FMI table SAE standard FMI
Display text
SAE text
0
“Value too high”
Valid data, but above the normal working range
1
“Value too low”
Valid data, but below the normal working range
2
“Faulty data”
Intermittent or faulty data
3
“Electrical fault”
Abnormally high voltage or short circuit to higher voltage
4
“Electrical fault”
Abnormally low voltage or short circuit to lower voltage
5
“Electrical fault”
Abnormally low current or open circuit
6
“Electrical fault”
Abnormally high current or short circuit to battery negative
7
“Mechanical fault”
Faulty response from mechanical system
8
“Mechanical or electrical fault”
Abnormal frequency
9
“Communication fault”
Abnormal updating rate
10
“Mechanical or electrical fault”
Abnormally large variations
11
“Unknown fault”
Unidentified fault
12
“Component fault”
Faulty unit or component
13
“Faulty calibration”
Calibration values outside the limits
14
“Unknown fault”
Special instructions
15
Data valid but above normal operating range - least severe level
16
Data valid but above normal operating range - moderately severe level
17
Data valid but above normal operating range - least severe level
18
Data valid but above normal operating range - moderately severe level
19
Received network data in error
20
Reserved for SAE assignment
21
Reserved for SAE assignment
22
Reserved for SAE assignment
23
Reserved for SAE assignment
24
Reserved for SAE assignment
25
Reserved for SAE assignment
26
Reserved for SAE assignment
27
Reserved for SAE assignment
28
Reserved for SAE assignment
29
Reserved for SAE assignment
30
Reserved for SAE assignment
31
Condition exist
