Wiring diagrams
Engines: TAMD74C-A/B, TAMD74L-A/B, TAMD74P-A/B (24 V)
1. 2. 3. 4. 5. 6. 7. 8. 9.
Batteries (24 V) Main switch Starter motor Alternator Starter relay Main relay Fuse (7.5 A) Oil pressure sensor, reverse gear Pressure sensor, charge pressure
Cable colour BL LBL BN LBN GN GR OR
= = = = = = =
Blue Light blue Brown Light brown Green Grey Orange
P PU R SB VO W Y
= = = = = = =
Pink Purple Red Black Violet White Yellow
10. 11. 12. 13. 14. 15. 16. 17. 18.
Oil pressure monitor, engine Oil pressure sensor, engine Coolant temperature sensor Circuit breaker (8 A) Stop relay Connector, instrument panel Connector, controls Connector, diagnostic connector Control unit EDC
19. 20. 21. 22. 23. 24. 25. 26.
Temperature sensor, charge air Coolant temperature sensor EDC Position sensor, control rod Engine speed sensor Control solenoid EDC Connector, reverse gear Solenoid, reverse gear Injection pump
Cable areas (mm²) are specified after the colour code in wiring diagrams. Unspecified areas = 1.0 mm². A broken line indicates a non Volvo Penta cable.
