Wiring diagrams
Engine: TAMD72P-A (24 V)
1. 2. 3. 4. 5. 6. 7. 8. 9.
Batteries (24 V) Main switch Starter motor Alternator Starter relay Main relay Stop relay Circuit breakers (8 A) Pressure sensor reverse gear
10. 11. 12. 13. 14. 15. 16. 17. 18.
Cable colour BL LBL BN LBN GN GR OR
= = = = = = =
Blue Light blue Brown Light brown Green Grey Orange
P PU R SB VO W Y
= = = = = = =
Pink Purple Red Black Violet White Yellow
Pressure sensor turbo Pressure monitor oil Oil pressure sensor Coolant temperature sensor Connector instrument panel Connector controls Connector diagnostic connector Control unit Temperature sensor charge air
19. 20. 21. 22. 23. 24. 25.
Temperature sensor coolant Position sensor, control rod Engine speed sensor Control solenoid EDC Connector reverse gear Shift solenoid, reverse gear Injection pump
Cable areas (mm²) are specified after the colour code in wiring diagrams. Unspecified areas = 1.0 mm². A broken line indicates a non Volvo Penta cable.
