Wiring diagrams
Engine: TAMD72P-A (12 V)
1. 2. 3. 4. 5. 6. 7. 8. 9.
Batteries (12 V) Main switch Connector Starter motor Alternator Starter relay Main relay Pressure sensor reverse gear Pressure sensor turbo
10. 11. 12. 13. 14. 15. 16. 17. 18. 19.
Cable colour BL LBL BN LBN GN GR OR 12
= = = = = = =
Blue Light blue Brown Light brown Green Grey Orange
P PU R SB VO W Y
= = = = = = =
Pink Purple Red Black Violet White Yellow
Pressure monitor oil Oil pressure sensor Coolant temperature sensor Circuit breakers (8 A) Stop relay Connector instrument panel Connector controls Connector diagnostic connector Control unit Temperature sensor charge air
20. 21. 22. 23. 24. 25. 26.
Temperature sensor coolant Position sensor, control rod Engine speed sensor Control solenoid EDC Connector reverse gear Shift solenoid, reverse gear Injection pump
Cable areas (mm²) are specified after the colour code in wiring diagrams. Unspecified areas = 1.0 mm². A broken line indicates a non Volvo Penta cable.
