Wiring diagrams
Engines: TAMD72WJ-A* (12 V, 24 V) * As from. engine No. 207181084/xxxx.
1. 2. 3. 4. 5. 6.
Batteries (12 V, 24 V) Main switch Starter motor Alternator Fuel shut-off valve Fuse
7. 8. 9. 10. 11. 12.
Cable colour BL LBL BN LBN GN GR OR
= = = = = = =
Blue Light blue Brown Light brown Green Grey Orange
P PU R SB VO W Y
= = = = = = =
Pink Purple Red Black Violet White Yellow
Stop relay Starter relay Circuit breakers (8 A) Earthing point Connector Engine speed sensor
13. 14. 15. 16. 17. 18.
Coolant temperature monitor Coolant temperature sensor Oil pressure monitor, engine Oil pressure sensor, engine Pressure sensor, charge pressure Oil pressure sensor, reverse gear
Cable areas (mm²) are specified after the colour code in wiring diagrams. Unspecified areas = 1.0 mm². A broken line indicates a non Volvo Penta cable.
