Wiring diagrams
Engines: TAMD61A*, TAMD62A, TAMD71A*, TAMD71B**, TAMD72A, TAMD72WJ-A** (12 V, 24 V) * As from. engine No. 1101021542/xxxx. ** Up to engine No. 207181083/xxxx.
1. 2. 3. 4. 5. 6. 7. 8. 9.
Batteries (12V, 24V) Main switch Starting heater High power relay Starter motor Alternator Stop solenoid Circuit breaker, 8A (+) Circuit breaker, 8A (–)
10. 11. 12. 13. 14. 15. 16.
Cable colour BL LBL BN LBN GN GR OR 8
= = = = = = =
Blue Light blue Brown Light brown Green Grey Orange
P PU R SB VO W Y
= = = = = = =
Pink Purple Red Black Violet White Yellow
Engine speed sensor Oil pressure sensor, reverse gear Oil pressure monitor, engine Oil pressure sensor, engine Pressure sensor, charge pressure Coolant temperature monitor Coolant temperature sensor
17. 18. 19. 20. 21. 22. 23. 24.
Starter relay Fuse 8A (24V), and 16A (12V) Timer relay Stop relay Earthing point Connector, instrument panel Earth cable Fuse (150A)
Cable areas (mm²) are specified after the colour code in wiring diagrams. Unspecified areas = 1.0 mm². A broken line indicates a non Volvo Penta cable.
