4 Maintenance
VD01143
Checking engine oil level Daily, before starting.
VD00155
VD01052
1 Check oil level
2 Oil level
3 Topping up oil
Turn the engine off. The dipstick is located on the starboard side of the engine.
The oil level must be at or near the upper mark on the dipstick*. If necessary top up with the same brand and type of oil.
The oil filling cap is on top of the the valve cover,.
*) The difference between the two oil level marks is: 1.9 litres (3.3 UK pt, 4 US pt)
32
A second oil filling cap is located at the distrubution cover, see page 18.
