Removing the Keyboard 1. See “Removing the Battery Pack” on page 46. 2. See “Removing the Switch Cover” on page 59. 3. Remove the two screws securing the keyboard to the upper case.
Step Keyboard
Size 2
Quantity
Screw Type
M2*3
4. Lift the keyboard as shown to remove from the chassis.
5. Turn the keyboard over and pull back the securing latch to release the FFC.
Chapter 3
61
