Information PhoenixBIOS Setup Utility . Info.
Main
CPU Type: : CPU Speed :
Advanced
Security
Boot
Exit
Intel(R) Pentium(R) M processor 1.86GHz 1866 MHz
HDD Model Name: ST9100822A HDD Serial Number: 3LG0Y4FE HATAPI Device: Slimtype DVDRW S0SW-833S System BIOS Version: 3A02 VGA BIOS Version: ATi 009.010.002.023 KBC Version:
1A11
Serial Number:
LXT123456705270008EF00
Asset Tag Number: Product Name: Manufacturer Name:
Aspire 5510 Acer
UUID:
003B4852C5630010A0EA00C09FAE9B34
F1 Help
↑ ↓ ←→
Esc Exit
Select Item
F5/F6 Change Values
F9 Setup Defaults
Select Menu
Enter Select 4 Sub- Menu
F10 Save and Exit
Parameter
49
Description
CPU Type
This item will show the CPU information of the system.
CPU Speed
This item will show the CPU clock speed.
HDD Model Name
This item will show the Model name of HDD installed on Primary IDE master. The hard disk model name is automatically detected by the system. If there is no hard disk present or unknown type, “None” should be shown on this field
HDD Serial Number
This item will show the Serial number of HDD installed on Primary IDE master. If no Hard disk or other devices are installed on Primary IDE master, then it will display a blank line
ATAPI Model Name
This item will show the model name of DVD/CD-ROM drive installed on system. The DVD/CD-ROM model name is automatically detected by the system. If there is no DVD/CD-ROM model present or unknown type, “None” should be shown on this field
System BIOS Version
This field reports the BIOS version of system
VGA BIOS Version
This field reports the VGA version of the system
KBC Version
This field reports the keyboard controller version of the system
Serial Number
This item will show the Serial number of system.
Asset Tag Number
This item will show the Asset Tag number of the system. Chapter 2
