REMOVING AND CARRYING THE MOTOR 61
EFO type Lay the engine with the shift lever up.
3. Storing the outboard motor Keep the motor in a vertical position when you store it.
Note If you can not carry the engine in an upright position, loosen the drain screw on the carburetors to drain fuel from them.
Note If you store the motor in a horizontal position, lay the motor as shown in figure of below.
To secure To loosen
6
EF, EFO, EPO Type
!
�������
Beware of explosion danger. Spilled and vapored gasoline may easily catch fire and explode. Be sure to fully discharge gasoline from the carburetors when transporting the engine. Wipe off spilled gasoline with a rag.
M60-140_E_body_110201.indd 61
!
�������
When taking the motor from package or removing the motor from the boat, never release the lock lever. If the lock lever is released, it will be very easy the clamp bracket to spring up to the tilting direction because it is not fixed.
