ENGINE TECHNICAL DATA N45 The technical code and serial number are indicated on a plate, which is located on different parts of the engine, according to the model: flywheel casing, tappet cover, other.
IMPORTANT! Any alteration of the above mentioned specifications are strictly prohibited, and will result in the product warranty
policy and the certification on the modified product becoming NULL and VOID.
N45 Engine family
F4
Cycle
4-stroke diesel
Number and arrangement of cylinders
4, in line
Bore x stroke
104 x 132 mm
Total displacement
4,485 cm3
Air system
Turbocharged - with intercooler
Engine direction of rotation
Counterclockwise (seen from flywheel side)
Dry weight
402 kg
Electrical system
24V
14
