Tigercat H855C/LH855C Harvester
Safety
IMPORTANT
SERVICING SAFETY PRECAUTIONS continued
PRESSURIZED HYDRAULIC TANK.
34.5 kPa (5 psi) MAXIMUM. Before servicing hydraulic system, wearing eye protection, release air pressure from FILTER tank using air vent valve.
The radiator and the engine cooling system should be cleaned and serviced daily to maintain moderate engine temperatures.
AIR VENT VALVE HANDLE
WARNING
BREATHER
SCHRADER VALVE MANIFOLD
845C-097 845C-001
WARNING, HOT FLUIDS AND HOT MACHINE SURFACES CAN CAUSE SERIOUS BURNS! •
Before servicing the machine, allow the engine cooling system, fuel system, exhaust system, hydraulic system and machine surfaces to cool down.
•
Use a thermometer to check surface and system temperatures to ensure it is safe to begin service work.
•
DO NOT begin service work until the surface or system temperature has cooled to below 38°C (100°F).
AIR VENT EXHAUST
PRESSURE GAUGE
After service is completed, close air vent valve and add air pressure from a clean air source to the hydraulic tank via the schrader valve. Do not exceed 34.5 kPa (5 psi). Refer to HYDRAULIC TANK PRESSURIZATION INSTRUCTIONS in SECTION 3 of THIS MANUAL for details.
1.23
