Tigercat H855C/LH855C Harvester
Safety CABLE ASSIST MOUNT
OPERATING SAFETY PRECAUTIONS continued
The cable assist mount can be used with a single or double shackle configuration depending on the winch system. Use only shackles with a pin diameter of 21⁄2 in. and rated for 55 tonne (121,000 lbf).
CABLE ASSIST The leveler cable assist mount may improve machine maneuverability on steep slopes when attached to a suitable winching device. Factors that will affect the safety of the machine as it works on steep slopes are: • Direction of machine travel • Limitations of machine tractive effort and soil conditions • Experience of the operator • Weather
B
• Load sizes (boom position and load)
A
• Poor visibility/lighting conditions
855D-036
DAILY CHECKS
A B
On a daily basis prior to operating the equipment check:
Single Shackle Configuration
Shackle Cable Assist Mount
• All equipment fluid levels. • Maintain a clean cab interior, clear away trash or debris. • Secure loose items in the cab. • Do not store tools, oil containers or other equipment in the cab • Functional check of all escape hatches. • All covers, roof and doors are closed and latched. • The cable assist mount for structural cracks and loose or missing bolts.
855D-037
On a weekly basis check the torque tightening points on the cable assist mount. Make sure the M24 bolts have a torque value of 915 Nm (675 lbf-ft).
A B
A
B
Double Shackle Configuration
Shackle Cable Assist Mount
WARNING
For additional information refer to MACHINE STABILITY AND TRACTION – MACHINES WITH LEVELER in THIS SECTION.
CAUTION Do not open cab doors or window screens when cab is on a slope. The doors and screens are heavy and could swing out with considerable force. Anyone in the path of swing could be injured. Anyone opening the door or screen and holding on to it could be pulled out of the cab and injured.
The lifting bail on the cable assist mount is for installation of the cable assist mount only. Do not use the lifting bail for anything other than its intended use. 1.15
