Tigercat H855C/LH855C Harvester
Safety
IMPORTANT
SERVICING SAFETY PRECAUTIONS continued
PRESSURIZED HYDRAULIC TANK.
34.5 kPa (5 psi) MAXIMUM. Before servicing hydraulic system, wearing eye protection, release air pressure from tank using air vent valve.
The radiator and the engine cooling system should be cleaned and serviced daily to maintain moderate engine temperatures.
WARNING
FILTER BREATHER
AIR VENT VALVE HANDLE
MANIFOLD PRESSURE GAUGE
Warning, HOT FLUIDS and hot machine surfaces can cause serious burns! •
Before servicing the machine, allow the engine cooling system, fuel system, exhaust system, hydraulic system and machine surfaces to cool down.
•
Use a thermometer to check surface and system temperatures to ensure it is safe to begin service work.
•
DO NOT begin service work until the surface or system temperature has cooled down to below 100°F (38°C)!
S855C-001a H855C-001
AIR VENT EXHAUST
SCHRADER VALVE
After service is completed, close air vent valve and add air pressure from a clean air source to the hydraulic tank via the schrader valve. Do not exceed 34.5 kPa (5 psi). Refer to HYDRAULIC TANK PRESSURIZATION INSTRUCTIONS in section 3 of this manual for details.
1.20
