Tigercat IMPORTANT! Any alteration of the above mentioned specifications are strictly prohibited, and will result in the product warranty policy and
ENGINE TECHNICAL DATA C87 The technical code and serial number are indicated on a plate, which is located on different parts of the engine, according to the model: flywheel casing, tappet cover, other.
the certification on the modified product becoming NULL and VOID.
C87 Engine family
F2C
Cycle
4-stroke diesel
Number of cylinders
6, in line
Bore x stroke
117 x 135 mm
(4.6 x 5.3 in.)
Total displacement
8,709 cm3
(531 in.3)
Air system
Turbocharged - aftercooled
Injection type Direct - high pressure pump supply and common rail system Engine direction of rotation
counterclockwise (seen from flywheel side)
Compression ratio
15.9 : 1
Cooling
Liquid
Dry weight
800 kg
Electrical system
24V
(1764 lbs)
13
