Tigercat 720E Feller Buncher
Safety SWITCH
OPERATING SAFETY PRECAUTIONS continued
•
When travelling on public roads, use accessory lights (when installed) and other cautionary devices to provide operators of other vehicles warning of your approach. Ensure your machine meets all regulatory requirements.
•• ACTUATOR
When transporting the machine watch that enough clearance is available on both sides and above the machine or any of its attachments to avoid contact with power or telephone lines, bridge structures, etc.
INTERLOCK SWITCH (L.H. DOOR SHOWN)
197-5
SAFETY INTERLOCK SWITCHES ON DOORS: Both doors are equipped with safety interlock switches to prevent the machine from being operated while either of the doors are open (pilot system is shut off).
Before transporting the machine check to ensure that all doors, panels and access covers are installed properly and secured.
IMPORTANT
CAUTION
24 VOLT
Safety interlock switches DO NOT lock out the steering function on machines equipped with a steering wheel.
ELECTRICAL SYSTEM
CAUTION DO NOT use the steering joystick to assist entering or leaving the cab. NOTE: The engine can be started but the machine functions cannot be operated with a door open. To operate: Close both doors and press the PILOT RESET switch.
CAUTION All functions on the machine can now be operated, either as intended or by accidentally touching them. Once the safety interlock system has been activated, the safety of both the operator and all persons outside the cab becomes the responsibility of the operator. The door safety interlock switches and the pilot reset switch are a safety feature and their function must not be defeated in any way.
1.9
