Safety
Tigercat 234B Loader When parking a machine with self-propelled option:
250D-076
•
Park on level ground.
•
Do not park on a hillside or incline.
•
Take the machine out of DRIVE MODE. This will automatically engage the park brake.
•
Lower the stabilizers to the ground.
•
Park the grapple in it's proper location on the carrier or rest on the ground.
•
Stop the engine.
•
NOTE: As a safety precaution before working on or around the machine, release brake system pressure by fully applying the brake foot pedal 40 times or more.
BATTERY DISCONNECT SWITCH
Turn the battery disconnect switch off if the vehicle is to be idle for an extended period of time (Example – overnight). Before transporting the machine: • Secure the grapple to the trailer and raise the stabilizers.
The pedal should have a 'soft' feeling when the pressure has been released
• Shut down the engine and turn the master disconnect switch off.
Pressure may remain in the system after completing the above. Use caution when loosening hydraulic connections.
• Check to ensure that all doors, panels and access covers are installed and properly secured.
•
Turn the machine battery disconnect switch off if the vehicle is to be parked for an extended period of time (Example – overnight).
NOTE: Wait 30 seconds after engine shut down before turning off battery disconnect switch. If battery disconnect is turned off before this the engine ECU (Engine Control Unit) will register a fault. When transporting the machine watch that enough clearance is available on both sides and above the machine or any of its attachments to avoid contact with power or telephone lines, bridge structures, etc. Before transporting the machine check to ensure that all doors, panels and access covers are installed properly and secured. Improperly secured doors or panels pose a serious danger to pedestrians and other vehicles. NOTE: This machine is equipped with an After Run/ Accessory Relay which delays the power disconnect to engine related fuses and relays (ECU /ATS relay, NOx Sensor relay, NOx Sensor fuse, ECU Power fuse, DCU fuse). Whenever the engine is stopped all DEF solution is pumped back to tank before the engine power system is turned off. This process takes approximately 90 seconds. Refer to SELECTIVE CATALYTIC REDUCTION SYSTEM in SECTION 3 for more information. 1.10
