Tigercat 220C Loader
Lubrication and Maintenance
PREVENTIVE MAINTENANCE SCHEDULE NEW MACHINE MAINTENANCE
*INITIAL PRE-DELIVERY INSPECTION:PERFORM THE INITIAL PRE-DELIVERY INSPECTION USING Tigercat FORM NUMBERS 5281 AND 5282; "PDI AND 50-100 HOUR INSPECTION REPORT"
*FIRST 50-100 HOUR INSPECTION AND SERVICE REPORT:WITH THE OWNER'S MECHANIC PRESENT, PERFORM AN INSPECTION AND SERVICE ACCORDING TO THE Tigercat FORM NUMBERS 5281 AND 5282; "PDI AND 50-100 HOUR INSPECTION REPORT" THIS MUST BE COMPLETED WITHIN THE FIRST 50-100 HOUR TIME FRAME.
*IMPORTANT: TO QUALIFY FOR CONTINUED WARRANTY, THIS REPORT MUST BE COMPLETED AND RETURNED TO Tigercat Industries Inc. WARRANTY DEPARTMENT.
Tightening points:~
NOTE: Use of filters other than genuine Tigercat replacement filters is not recommended.
All hydraulic connections Hose clamps Pin retainers Check torque on swing bearing retaining bolts
Refer to diesel engine service manual and attachment manual for additional required maintenance at this scheduled time period.
Engine mounting bolts Pump mounting bolts Pilot pump mounting bolts Swing gearbox mounting bolts
CAUTION
Swing motor mounting bolts
All handles, steps and platforms must be kept free of grease, oil, fuel mud, snow ice and forest debris to prevent risk of personal injury.
Cab securing bolts Boom pin nuts Heel pin nuts Trailer mounting studs Any other loose nut, bolt or fitting
*OIL LOST FROM LEAKAGE
LEAKAGE RATE ONE DROP IN 10 SECONDS ONE DROP IN 5 SECONDS ONE DROP PER SECOND THREE DROP PER SECOND DROPS BREAK INTO STREAM
PER DAY 0.424 0.852 4.26 14.2 90.83
LOST 0IL (LITERS) PER PER MONTH YEAR 12.72 152.0 25.6 306.6 127.76 1533.1 425.86 5110.31 2725.5 32706.0
3.2
PER DAY 0.112 0.225 1.125 3.75 24.00
LOST 0IL (GALLONS) PER PER MONTH YEAR 3.36 40.0 6.75 81.0 33.75 405.0 112.5 1350.0 720.0 8640.0
