Tigercat 220 Loader
Lubrication and Maintenance
PREVENTIVE MAINTENANCE SCHEDULE FOR 220 LOADER NEW MACHINE MAINTENANCE
*INITIAL PRE-DELIVERY INSPECTION:PERFORM THE INITIAL PRE-DELIVERY INSPECTION USING Tigercat FORM NUMBERS 5281 AND 5282; "PDI AND 50-100 HOUR INSPECTION REPORT"
*FIRST 50-100 HOUR INSPECTION AND SERVICE REPORT:WITH THE OWNER'S MECHANIC PRESENT, PERFORM AN INSPECTION AND SERVICE ACCORDING TO THE Tigercat FORM NUMBERS 5281 AND 5282; "PDI AND 50-100 HOUR INSPECTION REPORT" THIS MUST BE COMPLETED WITHIN THE FIRST 50-100 HOUR TIME FRAME.
*IMPORTANT: TO QUALIFY FOR CONTINUED WARRANTY, THIS REPORT MUST BE COMPLETED AND RETURNED TO Tigercat Industries Inc. WARRANTY DEPARTMENT.
Tightening points:~
NOTE: Use of filters other than genuine Tigercat replacement filters is not recommended.
All hydraulic connections Hose clamps Pin retainers Check torque on swing bearing retaining bolts
Refer to diesel engine service manual and attachment manual for additional required maintenance at this scheduled time period.
Engine mounting bolts Pump mounting bolts Pilot pump mounting bolts Swing gearbox mounting bolts
OIL LOST FROM LEAKAGE
Swing motor mounting bolts Cab securing bolts
LEAKAGE RATE ONE DROP IN 10 SECONDS ONE DROP IN 5 SECONDS ONE DROP SECOND THREE DROP PER SECOND DROPS BREAK INTO STREAM
Boom pin nuts Trailer mounting studs Any other loose nut, bolt or fitting
3.2
LOST 0IL (GALLONS) PER PER PER DAY MONTH YEAR 0.112 3.36 40.0 0.225 6.75 81.0 1.125 33.75 405.0 3.75 112.5 1,350.0 24.00 720.0 8,640.0
