TRANSPORTING INSTRUCTIONS
Position crane and attachment as shown with the highest point of the boom lower than the height of the cab. Refer to POSITION CRANE AND ATTACHMENT FOR TRANSPORT for instructions. DO NOT remove air from tires, this will result in damage to the tires! The articulation lock bar must be installed.
ARTICULATION LOCK BAR
The machine must be cross chained (side to side) using the two axles. Place blocks in front and behind wheels.
RETAINING PIN
ARTICULATION LOCK BAR
Additional chains may be attached on the front tow lug and the rear tow lug.
Attach chains to the tow lug using two chains per lug. DO NOT pass chains through the lug, a single chain will not prevent sideways movement. Note: Chains must be installed to prevent forward, reverse and side movement. IMPORTANT ! Do not use the center joint to chain the machine to the truck. This can damage the center joint 11
