Functions of and How to Use Adjustment Mode Other Functions and How to Use Them
ratio appears. Select it by pressing the register key. Display:
1. Language
[:Disp. Late data↓] ↓↑
The menu [Language] is used to change the
[:Disp. Max. data]
language for message appearing on the moment display. The message on the menu [Language] is
3. Display of latest overload data
always displayed in English.
The selection of [:Disp. Late data↓] results in the latest registered overload history data being
1. Select the main menu [･Language] in the adjustment mode, and press the register key to
displayed. The time when overload history data
select the menu.
has been registered is indicated in the moment display.
2. When message for language selection appears,
To view the next data on record (up to 50 items),
operate the scroll-up or scroll-down key to display
press the scroll-down key.
the aimed language. Display example:
Moment display
[= Japanese ↓]
Display example: [99. 01. 23 12:35↓]
↓Press the scroll-down key. [: English]
Shows the number of registered items. (50 items maximum.)
The sign “=” at the left side of the message shows that the language is currently set to be used.
Serial number. (of overload data in order of lateness.)
3. When the aimed language is displayed, press the
Shows the overload ratio. (Max. 400%)
register key. After the registration, the sign “:” at the left side of message changes to “=”. Display example: [: English] ↓Press the register key. [=English] 4. Press the display alteration key to exit the menu. After this, the messages on the moment display
%
are switched to the newly set language.
2. Overload History Display The records of crane operations beyond overloading limit are displayed. You can choose between the displays of latest overload data and of the greatest overload data. 1. Select the main menu [･Disp. O/L data↓] in the adjustment mode, and press the register key to
IW301-0131E05
select the menu. 2. Use the scroll-up or scroll-down key until the menu of latest overload ratio or peak overload
