Troubleshoot Test explanation Step
Action
Value
Yes
No
Is there an emergency stop switch mounted?
-
Turn the switch "OFF" and Go to step 2. go to step 2.
2
1. Turn the key switch "ON". 2. Crank the engine for 15 sec. 3. Confirm the diagnostic trouble code. Was a diagnostic trouble code detected?
-
Go to diagnosis for the detected diagnostic trouble Go to step 3. code.
3
1. Inspect the PCV-LOW circuit between the ECM and PCV. 2. Correct the circuit as necessary if a problem is detected. Is the action complete?
-
Go to step 4.
4
1. Inspect whether any of the abnormalities listed below are present. ・ Lag in engine mechanical timing ・ Flywheel installation position problem ・ Excessive clogging in intake air system ・ Excessive clogging in exhaust system 2. Repair as necessary if a problem is detected. Was a problem detected?
-
Go to step 5.
5
1. Delete the diagnostic trouble code. 2. Turn the key switch "OFF" for at least 10 sec. 3. Start the engine. Was a problem detected?
-
Go to step 6.
6
Confirm the diagnostic trouble code. Was a diagnostic trouble code detected?
-
Check repair and go to Go to diagnosis for the detected diagnostic trouble "Trouble Diagnosis by Service Support". code.
