Equipment Layout Diagram
CO US N F E ID O E F N TS TI M AL GL : F O OR BA T L H
E
IN
TE RN
AL
Consumable Part Layout
1
Fuel tank
6
Hydraulic oil tank
11
Air conditioner outside air filter
2
Pilot filter
7
Return filter
12
Washer tank
3
Fuel prefilter
8
Tank air breather
13
Battery
4
Engine oil filter
9
Suction filter
14
Reserve tank
5
Fuel filter
10
Air cleaner
