Specifications 6. Upper Side Work System SH350LC-5 Model
SH350HD-5
SH370LHD-5
Backhoe attachment
Components, dimensions, working dimensions Heaped 1.40 m3
Heaped 1.60 m3
AL
Standard bucket capacity
3
(leveled 1.17 m3)
(leveled 1.04 m ) 1300 mm
1310 mm
1450 mm
Bucket width with side cutter
1435 mm
1425 mm
1565 mm
Bucket weight with side cutter
1160 kg
1490 kg
1570 kg
Boom length
6450 mm
Arm type
Standard Long (STD/HD) (4.04 m) (3.25 m)
Standard Short (HD) (HD) (3.25 m) (2.63 m)
Standard (HD) (3.25 m)
Arm length
3250 mm 4040 mm 2630 mm 3250 mm 2630 mm 3250 mm 2630 mm
IN
1680 mm
CO US N F E ID O E F N TS TI M AL GL : F O OR BA T L H
Bucket radius
Bucket wrist angle
Maximum digging radius
Short (HD) (2.63 m)
E
Short (2.63 m)
TE RN
Bucket width
173°
11170 mm 11900 mm 10670 mm 11170 mm 10670 mm 11170 mm 10670 mm
Maximum digging radius at ground 10980 mm 11720 mm 10470 mm 10980 mm 10470 mm 10980 mm 10470 mm line Maximum digging depth
7340 mm 8140 mm 6730 mm 7340 mm 6730 mm 7340 mm 6730 mm
Maximum vertical straight wall dig6350 mm 7150 mm 5970 mm 6350 mm 5970 mm 6350 mm 5970 mm ging depth Maximum digging height
10370 mm 10670 mm 10320 mm 10370 mm 10320 mm 10370 mm 10320 mm
Maximum dump height
7230 mm 7540 mm 7140 mm 7230 mm 7140 mm 7230 mm 7140 mm
Minimum swing radius at front
4500 mm 4560 mm 4630 mm 4500 mm 4630 mm 4500 mm 4630 mm
Height for minimum swing radius 8480 mm 8490 mm 8540 mm 8480 mm 8540 mm 8480 mm 8540 mm at front
7. Operating Device
SH350LC-5/SH350HD-5/SH370LHD-5
Operator's seat Position
Left side
Structure
Adjustable forward and back and up and down, reclining mechanism, with seat suspension
Cab
Sealed steel type, all reinforced glass
Levers and pedals For travel use
Lever and pedal type (hydraulic pilot type)
x2
For operating machine use
Lever type (hydraulic pilot type)
x2
Instruments and switches Work mode select switch
3 modes (SP/H/A)
Travel mode select switch
Low-speed / high-speed switch type
One-touch idle
Knob switch type 3
