Counterweight Removal and Installation of Counterweight ・ Be sure to stop the engine before beginning work. ・ Be sure to inspect the wire rope and other lifting equipment before beginning work. Caution ・ Do not stand or pass under the suspended load. ・ Thoroughly secure the removed counterweight with the wire ropes and crane so that it does not fall over.
Items to prepare • Box wrench (50 mm) • Eyebolts (M36 mm) • Balance lifting device • Shackle (with the required lifting capacity) x 4 • Wire rope (with the required breaking load) x 4 • Crane (with the required lifting capacity) • Wood planks, etc. • Rag
1. Removal of Counterweight
CO US N F E ID O E F N TS TI M AL GL : F O OR BA T L H
E
IN
TE
RN
[1] Remove the 2 rubber plugs (2) from the top of the counterweight (1).
AL
• Cleaning fluid
[2] Install the 2 eyebolts (M36) (3) in place of the 2 removed rubber plugs. • Apply lubricating oil to the eyebolts. • Fully tighten the eyebolts, and then loosen them by a half turn.
222
1
Counterweight
2
Rubber plug
3
Eyebolt
RSM-13-08-001E 1
