GENERAL SPECIFICATIONS Shipping Weight
28.3 metric tons (62,400 lb), includes 10% fuel, boom, 3,100 mm (10’ 2") arm, 1,334 mm (4’ 5") backhoe bucket and standard shoes
Operating Weight
Add weight of full fuel tank and operator.
Shipping Weights With Optional Track Shoes
Add 600 kg (1,320 lb) for 700 mm (28") shoes Add 900 kg (1,984 lb) for 800 mm (32") shoes Add 1050 kg (2,315 lb) for 850 mm (34") shoes
Major Component Weights
Standard Boom 2,000 kg (4,410 lb) 2,400 mm (7’ 10") Arm 780 kg (1,720 lb) 3,100 mm (10’ 2") Arm 950 kg (2,094 lb) 3,750 mm (12’ 4") Arm 960 kg (2,117 lb) 5,000 mm (16’ 5") Arm 1,100 kg (2,46 lb) Boom Cylinders 260 kg (573 lb) each Arm Cylinder 340 kg (750 lb) Bucket Cylinder 220 kg (485 lb) Counterweight 4,500 kg (9,920 lb) Upper Turntable 7,100 kg (15,653 lb) Lower - below Swing Bearing 10,800 kg (23,810 lb)
Digging Forces: Bucket Cylinder
177 KN or 18,100 kg (39,900 lb) - (with either 3,100 mm [10’ 2"] or 2,400 mm [7’ 10"] arm)
Arm Cylinder
131 KN or 13,400 kg (29,500 lb) with 3,100 mm (10’ 2") standard arm
Fuel Tank Capacity
435 liters (115 gal)
Hydraulic System Capacity
260 liters (69 gal)
Hydraulic Reservoir Capacity
205 liters (54 gal)
Bucket Heaped Capacity Range
PCSA 0.90 - 1.5 cu. m (1.18 - 1.96 cu. yd.) IMPORTANT: Refer to the Load Weight, Bucket and Arm Length Compatibility Table for information on which bucket sizes may be used safely with which arm length, for load material weights.
Shoe Type
Triple Grouser
Shoe Width and Optional Sizes
600 mm (23.5") - standard 700 mm (28") - optional 800 mm (32") - optional 850 mm (34") - optional 910 mm (36") - special option (triangular)
Ground Pressure Ratings: Standard 600 mm (23.6") shoe -
0.54 kg/cu. cm (7.7 psi)
Optional 700 mm (28.0") shoe -
0.47 kg/cu. cm (6.7 psi)
Optional 800 mm (32.0") shoe -
0.42 kg/cu. cm (6.0 psi)
S0202000 Page 8
Specifications for Solar 290LC-V
