Troubleshooting
External oil leakage Impurities entering the retarder will shorten its service life. Therefore, clean the outside of the retarder thoroughly before detaching hoses, covers and similar parts.
25
29
5 10:2192
16 28 The numbers in the text refer to the illustrations under the headings Valve housing and Retarder housing. Checks for external oil leakage
5 Valve housing 16 Valve housing cover 25 Air filter 28 Oil sump cover 29 Plug
Check the air filter 25 Action
Check whether the oil level is too high. If there is water in the oil, the retarder oil cooler is defective.
03 0925
An improved air filter has been introduced to prevent oil leakage. The filter was introduced in production from chassis number SS1219748, SN4360756, SA9015143.
New air filter with restriction.
1050t14b.mkr
©
Scania CV AB 1999, Sweden
23
