– Remove the wiper arm WS 13 – Unscrew the nuts fixing the motor (WAF 22/WAF 24) – Remove the upper instrument panel (4 countersunk screws) – Remove the supporting sheet-metal panel for the steering column (remove screw on steering column WAF 17) – Remove the supporting sheet-metal panel upwards – Remove the lining on the right of the steering column (countersunk screws) – Separate the compact plug and the earthing cable through the lateral opening – Remove the wiper motor upwards through the opening of the instrument panel (wiring harness in the instrument panel is sufficiently long)
Removing the front wiper motor 520 / 620 wheel loaders (models 303 58 / 304 59)
