844/642 Telehandler
HYDRAULICS
STEP 66
STEP 68
G0805043
G0605047
Shut off the engine. Remove the pressure gauge from the cylinder port (1). Cap the port (1) and plug the gauge tee adapter (2).
STEP 67
G0805040
Shut off the engine. Remove the two hoses from the stabilizer cylinder. Install caps on the cylinder elbow fittings and plugs in the hose ends. G0505046
Start the engine and run at 1000 RPM. Hold the frame leveling joystick in the TILT RIGHT position. The pressure gauge should read 2500 psi (172 bar)
Remove the two hoses from the stabilizer cylinder. Install caps on the cylinder elbow fittings and plugs in the hose ends.
If the pressure is 2500 psi (172 bar), repair or replace the tilt cylinder. If the pressure is less than 2500 psi (172 bar), proceed to the next step.
