Item
Part No.
Name
Qty
Remarks
0
50309600
CYLINDER/TILT
1
1
L99860
PISTON
1
2
50293747
GLAND
1
3
50293748
CYLINDER ROD
1
4
50293749
BEARING
2
5
50293750
BEARING
2
6
L99122
Nut/1.75-12 Unf Lock
1
Torque to 2712-2982 Nm (2000-2200 ft.lbs.) loctite 271 or equivalent.
7
50292084
SELF-TAPPING SCREW
1
Install after gland torquing and cylinder testing. Requires drilling hole on gland/tube part line. Hole dimensions: 3.75-3.90 mm (0.147-0. 152 in.) dia. x 7.9 mm (0.31 in) deep, at 90 deg from the spanner holes. Torque to 2.25 Nm (20 ft.lbs.)
8
50293751
SEAL KIT (Incls. Ref. 10)
1
9
50292467
VALVE
1
10
L99073
Locking Insert
2
(50940507C) ALT708, MLA-T 516 Parts Manual
Complete cylinder
Torque to 45-50 Nm (33-37 ft.-lbs.)
Torque to 45-50 Nm (33-37 ft.-lbs.)
156
