Electrical/Control Systems Deutz Engine CAN/Computer Connection Harness (SerDia) (Model 2500RT) Deutz SerDia software provides CAN communication with the engine control system. Refer to the Manitou service manual “Deutz TD 3.6 L4 Engine Service Manual” [Manitou part # 50940203] and/or contact Deutz service for more information. .
Fig. 549 – Example Deutz SerDia Interface
Connection for the SerDia system is established using the Deutz engine data connector (Z, Fig. 550), located under the ROPS/FOPS near the engine ECU on the left side of the machine.
Z
Fig. 550 – Deutz SerDia Data Connector
