AL 206 - HYDRAULIC CYLINDERS TILT CYLINDER
6
8
1 Not serviceable
19 11
440 Nm
14
(325 lb.-ft.) 7
12 407 Nm
2
3 19
(300 lb.-ft.)
15
18
17
16
13
10
4 20
9
8
5
175799
Ref. No. Part No. 1
175799
Description
Qty.
TILT CYLINDER COMPLETE (Includes Ref. Nos. 2-19)
1
2
270575
PISTON
1
3
270576
HEAD GLAND
1
4
270577
ROD WELDMENT
1
5
270453
40MM SPHERICAL BEARING
2
6
270454
PRELUBRICATED BUSHING
2
7
080313
NUT LOCK 1.00-14 *
1
8
613052
FITTING/GREASE M6X1
2
9
270455
INT. SNAP RING 2.44 BORE
1
10
O-RING
1
11
O-RING
1
918312/AP0608
Ref. No. Part No.
Description
Qty.
12
O-RING
1
13
SQUARE RING
1
14
BACKUP RING
1
15
Z-SEAL
1
16
SQUARE SECT. TFE PISTON SEAL
1
17
HD ROD WIPER, SEALED OD
1
18
WEARBAND
1
19
LOCKING INSERT
2
KIT/SEAL (Includes Ref. Nos. 10-19)
1
20
270578
* Requires Loc-tite® 271 or equivalent.
38
