New 1000 Series To inspect
14 14-14
1 Clean all the components before inspection. 2 Check the gear teeth and the splines of the drive shaft for wear or other damage. Renew the drive shaft if necessary. 3 Check the idler gear, needle roller bearing, hub and thrust washer for wear or other damage. Renew the components if necessary. 4 Check the drive gear for the balance weights for wear or other damage. Renew the gear if necessary. 5 Check the balance weights for wear or other damage. If either balance weight is worn or damaged, both balance weights must be renewed. 6 Check the needle roller bearings for the drive shaft for wear or other damage. Renew the bearings, see operation 14-15, if necessary. 7 Check the bushes for the balance weights for wear or other damage. Renew the bushes, see operation 14-16, if necessary. 8 To inspect the lubricating oil pump, see operation 19-8.
Workshop Manual, TPD 1350, issue 3
101
