Repair Instructions H1 - 069/078, 089/100, 115/130, 147/165 Axial Piston Pumps Inspection Optional Integrated Filter Check all machined surfaces for nicks and scratches. Check the bypass valve poppet, spring, and seat. Check the bypass indicator switch operation. Replace damaged parts as necessary. Replace all seals and gaskets before reassembly. Inspect filter adapter and bypass valve
P106 140E
Clean and inspect all filter adapter parts. Check the gasket surfaces for nicks and scratches. Check the bypass valve poppet, spring, and seat. Check the bypass indicator switch operation. Replace damaged parts as necessary. Replace all seals and gaskets before reassembly.
P106 142E
