2 Function and use Cutaway view
1 2 3 4 5 6 7 8 9 10 11 12 13 14 15
Heater impeller Control box Combustion air fan impeller Glow plug Cover Heat exchanger Combination sensor (overheating / flame sensor) Radio remote control (mobile unit) Radio remote control (stationary unit) Button Temperature sensor (room temperature) Fuse bracket with main fuse and “actuation” fuse Electrical motor Fuel connection Flange seal
16 17 18 19 20 21 22
Combustion chamber Outlet hood Combustion air hose Metering pump Pot-type strainer, installed in the dosing pump Outflow Flexible exhaust pipe
F = W= A= B= V=
Fresh air Hot air Exhaust Fuel Combustion air
