5 Repair instructions Assembly drawing Airtronic / Airtronic M
Parts list 1 2 3 4 5 6 7
Combustion air fan Seal – combustion air fan / heat exchanger Combustion chamber Seal – combustion chamber / heat exchanger Heat exchanger Control box Combination sensor (overheating / flame sensor) with assembly tool
8 9 10 11 12 13 14
Bracket Glow plug, with special tool (SW 12) Lining – glow plug socket, with assembly tool Cover Outer shell (bottom section) Flange seal Sleeve (for petrol only)
