MOUNT KIT SERVICE PARTS BREAKDOWN SYM QTY PART DESCRIPTION 1 8 006667 Carriage Bolt, 1/2 x 1-1/2 NC ZP 2 1 006793 Socket Head Cap Screw, 5/16-18 x 1.75 3 2 006798 Hex Head Capscrew, 5/16-18 x 1.25 Gr 5 4 4 007028 Hex Head Capscrew, 1/2-20 x 1.50 Gr 5 5 2 007080 Hex Head Capscrew, 1/2-13 x 5.00 Gr 5 6 2 007136 Hex Head Capscrew, 5/8-18 x 1.75 Gr 5 SAE 7 3 007433 Nut, Hex 5/16-18 Gr 5 Lock 8 10 007508 Nut, Hex 1/2-13 Gr 5 Lock 9 6 007514 Nut, Flange 1/2-20 Lock Nylon 10 4 007519 Nut, Hex M14-2.0 Gr 10 Lock Nylon 11 2 007536 Nut, Hex 5/8-18 12 4 008151 Flat Washer 5/16 13 22 008164 Flat Washer 1/2 SAE Hardened 15 8 008176 Flat Washer 9/16 SAE Hardened 16 4 008178 Flat Washer 5/8 SAE Hardened 17 1 008547 Locking Ring 18 1 008554 Cotter Pin, 3/32 x 3/4 19 2 008675 Spring, Compression (Latch) 20 2 008679 Spring, Lift 21 1 013237 Retaining Ring 22 4 013358 Clevis Pin, 3/4 x 1-3/4 23 1 013467 Clevis Pin, 3/4 x 3-3/4 24 4 013491 Lynch Pin (1/4 Dia x 1.25) 24 2 013679 Rubber Bumper 25 2 014505 Fitting, Straight Grease 1/4-28 26 1 015583 PTO Drive Assembly 27 4 018654 Hex Head Cap Screw M12-1.75 x 45 Gr 10.9 FTHD 28 4 018725 Hex Head Cap Screw M14-2.0 x 40 Gr 10.9 29 1 066073 J-Latch 30 2 066168 Lift Rod Assembly 066170 Spring Pin only 31 1 451430 Latch Weldment 32 2 451784 Spacer Plate 33 2 451788 Front Mount Hanger Plate 34 2 451791 Shackle Plate 35 1 451799 Lift Stiffener Plate 36 1 451837 RH Hitch Plate 37 1 451838 LH Hitch Plate 38 1 451860 Front Link Weldment 39 1 451880 RH Mid Mount Weldment 40 1 451885 Lower Link Weldment 41 1 451895 LH Mid Mount Weldment 42 1 451905 RH Lift Weldment 43 1 451910 LH Lift Weldment 44 1 451920 RH Link Weldment 45 1 451925 LH Link Weldment
45
