LUBRICATION/FILTERS/FLUIDS
ENGINE LUBRICATION Service Specifications Oil Level Check Interval……………………………………………………………………………Daily Oil Change Interval……………………………………………………Every 100 hours (See NOTE) Oil Type…………………………………………………………See Lubrication Table in this manual. Oil Capacity .......Without Filter Change…………………………………………3.7 Liters (3.9 QTS) With Filter Change …........………………………………...…4.2 Liters (4.4 QTS)
NOTE: Change the engine oil after the first 50 hours of operation and then use the regular
change interval. Change the engine oil more frequently when the operating conditions are severe, such as, operating in very high or very low ambient temperatures, very dusty.
Engine Oil Level
ENGINE OIL DIPSTICK
To check the engine oil level, put the tractor on level ground and stop the engine. Pull the dipstick out, wipe the dipstick with a dry cloth and install the dipstick to check the oil level. If the oil level is below the A (Add) mark, add oil to raise the oil level to the F (Full) mark. Do not raise the oil level above the F (Full) mark.
ENGINE OIL DIPSTICK
FULL MARK ADD MARK
IMPORTANT: The level should be checked before starting or 5 minutes after the engine has
been shut off.
