INSTRUMENT/CONTROLS
OPERATORS SEAT I nstall the operator's seat with the pin and secure it with the cotter pin.
CONNECTORS
Connect the connectors. SEAT
PIN COTTER PIN
IMPORTANT: Check the switch as the following procedure after having installed the standard seat.
Checking the switch (1) Sit on the operator's seat (2) Apply the parking brake. (3) Shift the all operating control lever to "N" or "OFF". (4) Depress the clutch pedal. (5) Start the engine. (6) Shift the Mid PTO lever to "ON". (7) Leave the operator's seat. (8) M ake sure the engine must shut off. In case the Mid PTO is disengaged, the engine will remain running if you stand up.
NOTE: If you leave the seat when the Mid PTO is engaged, safety system will automatically shut down the engine. While engine is running, if you leave a seat, engine will shut off after one (1) second.
35
