LUBRICANTS AND FUEL CHART R 934 B Litronic COMPONENTS
SYMBOLS
VISCOSITY (SAE DIN 51512)
SPECIFICATIONS
QUANTITIES
1) With swing brake only used as a parking brake SAE 90 SWING GEAR
API GL-5 and MIL-L-2105 B, C or D
2) With swing brake also used as a service brake (Actuated via a foot pedal) SAE 90LS
5,5 l. 1.4 US gal
API GL-5 and MIL-L-2104 B, C or D MIL-L-2105 B
TRAVEL GEAR
SAE 90
API GL-5 and MIL-L-2105 B, C or D
2 × 7 l. 2×1.9 US gal
SPLITTERBOX
SAE 90
API GL-5 and MIL-L-2105 B, C or D
2 l. 0.53 Us gal
SWING RING TEETH
Special grease
See lubricants specifications
GENERAL LUBRICATIÓN POINTS
CONSISTENCY 2 NL GI N°2 Grade
MULTUPURPOSE GREASE KP2k or EP2 (Extreme pressure N°2 Grade)
Swing ring races Attachment bearings, Hinges, couplings, locks
Engine oil
Rubber seal on doors and covers
Silicon Spray or talcum 1,9 kg (4.5 lbs) / SN 14 323
REFRIGERATING AGENT FOR AIR CONDITIONER
R 134a
REFRIGERATOR OIL IN AIR CONDITIONER COMPRESSOR
PAG SP 20 (ELF)
0,21 l. ( 5 oz.)
WINDSHIELD WASHER SYSTEM
Commercial Windshield washer fluid or denatured alcohol
5 l. 1.3 US gal
5.3
1,4 kg (3.3 lbs) / SN 14 324
