PW/RW / BEAM (SHEAR BOLT) PosNo. 1 2 3 4 5 6 7 8 9 10 11 12 13 14 15 16 17 18 19 20 21 22 23
Part No. KK013009 KK015825 KK015830 KK016012 KK016022 KK016045 KK016049 KK032762 KK032824 KK032860 KK032865 KK035048R KK035072R KK035215 KK061515 KK071270R KK071271R KK071272R KK071273R KK071274 KK071275 KK071508 KK071529
© Kverneland Group
Qty.
Description WASHER 21,-X 35,-X7,5 EL.GALVANIZED NUT M16 NUT M20 FLANGE NUT M20 FLANGE NUT M30 10 KEY36 FLANGE NUT M30 LEFT KEY 36 FLANGE NUT M20 WITH LOCK HEX BOLT M16X60 12.9 HEX BOLT M20X105 10.9 HEX BOLT M20X60 10.9 HEX BOLT M20X65 10.9 SHEARBOLT M20X72 SHEAR BOLT M20X88 W/NUT HEX BOLT M20X80 W/NUT BUSHING D20.5-D28X35.2 CENTER SECT. SHEARBOLT BEAM H=800 CENTER SECT. SHEARBOLT BEAM H=700 RIGHT SECTION SHEARBOLT BEAM LEFT SECTION SHEARBOLT BEAM BOLT M30 R.HAND THREAD L=84 BOLT M30 L.HAND THREAD L= 84 PLATE FOR BEAM H=700 SIDE PLATE SHEARBOLT BEAM H=800
PW496-> < Mach. ID <= RW193->
Remark
Page number: 6
