PW/RW / BEAM - AUTO RESET PosNo. 1 2 3 4 5 6 7 8 9 10 11 12 13 14 15 16 17 18 19 20 21 22 23 24 25 26 27 28 29 30 31 32 33 34 35 36 37 38 39 40
Part No. KG01189662 KG01193962 KK015817 KK015830 KK016007 KK016012 KK029727 KK029920 KK032655 KK032665 KK032840 KK032860 KK035020R KK035021R KK035165 KK035209 KK035210 KK050706 KK057063 KK057064 KK057065 KK057066 KK057067 KK057068R KK057089 KK060108 KK060109 KK060703 KK061280R KK061291 KK067016R KK067025R KK067026R KK067031R KK067039R KK067051 KK067059R KK067075 KK067076 KK067077
© Kverneland Group
Qty.
Description TENSION PIN 6X40 TENSION PIN 10X40 NUT M12 GALV. NUT M20 FLANGE NUT M10 FLANGE NUT M20 SPLIT PIN D5X32 GREASE NIPPLE M8X1 STRAIGHT HEX BOLT M12 X 55 HEX BOLT M12X65 GL40 HEX BOLT M20X40 10.9 HEX BOLT M20X60 10.9 BOLT M10X34 BOLT M10X30.5 HEX BOLT M20X50 W/FLANGE NUT HEX BOLT M20X50 W/THREADED PIECE HEX SCREW M20 X 55 W/FLANGE NUT SPRING STANDARD CLP WITHOUT REGULATOR MAIN SPRING BLADE SPRING BLADE NO. 1 SPRING BLADE NO. 2 SPRING BLADE NO. 3 SPRING BLADE NO. 4 BLADE NO.5 SPRING BOLT DISTANCE BRACKET CPL. RIGHT DISTANCE BRACKET CPL. LEFT SPRING HD CPL. WITHOUT REGULATOR AUTO RESET LEG THREADED PIECE BOLT Ø25 FOR CLEVIS CLEVIS FOR TIE ROD D25 TIE ROD D22 WITH D22 & D25 HOLES MAINBOLT SCREW ADJUST SCREW W/THREADED PIECE AXLE SHACKLE BOLT D15.7-D5.5X168-D5.5 DISTANCE TUBE ADDITIONAL SPRING PACK
PW496-> < Mach. ID <= RW193->
Remark
Page number: 3
