6490 / DRIVE, NET WRAP PosNo. 1 2 3 4 5 6 7 8 9 10 11 12 13 14 15 16 17 18 19 20 21 22 23 24 25 26 27 28 29 30 31 32 33 34 35 36 37 38 39 40
Part No. AC674143 KG00353161 KG00472561 KG00474361 KG00638961 KG00641361 KG00642661 KG01000661 KG01052061 KG01061261 KG01068761 KG01068861 KG01099062 KG01267361 KG01306400 VGMH416V VGND3146V VGND3147V VGND3177V VGND5141 VGND6372 VGND95057 VGND96132 VGPZ477V VGRL02 VGRL1V VGRL171V VGRL172V VGRL173V VGRL224 VGRL265V VGRL50V VGRL51V VGRL52V VGRL55V VGRL56V VGRL569K0 VGRL8K0 VGWA02015 KG01308600
© Kverneland Group
Qty. 2 3 2 2 3 4 1 1 4 3 2 3 1 2 1 1 3 6 2 2 2 2 1 1 1 1 1 1 1 2 1 1 1 4 1 1 1 1 1 1
Description INA FREE WHEEL HFL 3030 HEX. BOLT M8X35 8.8 HEX. SCREW M8X45 8.8 HEX. SCREW M10X30 8.8 CARRIAGE BOLT M8X16 8.8 CARRIAGE BOLT M10X20 8.8 CARRIAGE BOLT M10X90 8.8 FLANGED BOLT M8X15 HEX. NUT M10 8 LOCK NUT M8 8 LOCK NUT M8 10 LOCK NUT M10 10 CIRCLIP-A 30 X 2 WASHER M8 KEY 8X7X20 RING RING RING WASHER, PLAIN CUSHION, BALL, ADJUSTABLE RING, SEALING CAP, PLASTIC V-BELT SPRING, COMPRESSION ROLLER PULLEY, V-BELT HUB DISC ROTOR DISC ROTOR BRAKE LINING PINION DISC ROTOR DISC ROTOR RING SLEEVE SLEEVE COVER, PLATE ROLLER, NYLON KEY 10X8X28
VGRL001345 < Mach. ID <=
Remark
Page number: 33
