PERIODIC SERVICE
51
DAILY CHECK
BEngine Side Cover 1. Tilt down the front grille forward. 2. Lift up the front of the engine side cover and free the upper and lower projections.
For your own safety and maximum service life of the machine, make a thorough daily inspection before operating the machine to start the engine.
To avoid personal injury: A Be sure to check and service the tractor on a level surface with the engine shut off and the parking brake "ON" and implement lowered to the ground.
BWalk Around Inspection Look around and under the tractor for such items as loose bolts, trash build-up, oil or coolant leaks, broken or worn parts.
(1) Engine side cover (2) Projection
(A) "LIFT UP TO REMOVE"
3. Pull the engine side cover forward and free the rear notches. Now the side cover can be detached.
(1) Engine side cover (2) Notch
