48
3-POINT HITCH & DRAWBAR
BCheck Chains Adjust the turnbuckle to control horizontal sway of the implement. See "Hydraulic Control Unit Use Reference Chart" in "AUXILIARY HYDRAULICS" in "HYDRAULIC UNIT" section. After adjustment, retighten the lock nut.
DRAWBAR To avoid personal injury: A Never pull from the top link, the rear axle or any point above the drawbar. Doing so could cause the tractor to tip over rearward causing personal injury or death.
BAdjusting Drawbar Length When towing an implement, recommend use of (B) hole in drawbar. The drawbar load is referred to "IMPLEMENT LIMITATIONS" section.
(1) Turnbuckle (2) Lock nut
BLower link holder When operating the tractor without a 3-point hitch implement, it is necessary to lock the lower links to prevent them from hitting the tractor rear wheels.
(1) PTO shaft (2) Drawbar (3) Pivot pin
Holes : (A),(B)
