REGULAR CHECKS AND MAINTENANCE WORK
BReplacing Hydraulic Return Filter Element (First replacement after 250 service hours)
71
EVERY 1000 SERVICE HOURS
Do all 50, 100, 200, 250 and 500 hour servicing at the same time.
BReplacing the Hydraulic Pilot Filter Element To avoid personal injury: A Remove the oil filter only after the oil in the hydraulic tank has cooled down.
1. 2. 3. 4. 5. 6.
7. 8. 9. (1) Set bolt (2) Filter support
To avoid personal injury: A Before replacing the element, wait long enough for the hydraulic fluid to cool down. Remove the bonnet left cover. Gradually loosen the oil filling plug on the tank to release the pressure in the hydraulic system. Remove the pilot filter case from the head cover. Wrench and pull out the element downward. Replace the O-ring with a new one. Apply a light coating of clean hydraulic oil to the O-ring and fit it to the case firmly. Be careful not to scratch the O-ring. Fit the case to the head cover. Let the engine run for approx. 3 minutes. Check the oil level of hydraulic oil tank, then tighten the oil filling plug.
(3) Return filter (4) Cover
1. Remove the cover of the hydraulic tank. 2. Pull out the filter support by the top plate from the hydraulic tank. 3. Remove the return filter from the filter support with a fork wrench and exchange the filter. A Always check the oil level when replacing the filter.
BReplacing Breather Filter See "Replacing Hydraulic Return Filter Element" in "EVERY 500 SERVICE HOURS" section.
(1) Bonnet left cover
BReplacing Fan Belt Consult your local KUBOTA Dealer for this service.
(1) Head cover
(2) Element
(3) O-ring
(4) Case
