70
REGULAR CHECKS AND MAINTENANCE WORK
EVERY 500 SERVICE HOURS
Do all 50, 100 and 250 hour servicing at the same time.
BDrive unit Oil Change(First Oil Change of the 50 hours)
To avoid personal injury: A Lower all attachments to the ground, stop the engine and remove the key before undertaking the oil change.
BReplacing Fuel Filter Cartridge
To avoid personal injury: A Keep fire away. 1. Remove the filter with the filter wrench. 2. Apply a light film of fuel to the seal of the new filter and turn in tightly by hand. 3. Open the cock of the fuel filter again.
1. Rotate the track so that the drain plug of the drive unit is in the bottom position. 2. Remove the drain plug to let the oil run out. Screw in and tighten the drain plug again and fill with gear oil through the oil check port. 3. Fill oil until it overflows out of the oil check port. Oil change - first oil change after 50 hrs - then every 500 hrs - or at least once a year 4. Use prescribed gear oil SAE 90. (1) Fuel filter cartridge
A After exchange of the filter, the fuel system must be purged of air.
(1) Oil check port (2) Drain plug (3) Oil filling port
Gear oil volume
approx. 0.6 L
