CHECKS BEFORE START
21
AIR CONDITIONER BAir Flow Air in the CAB and fresh air introduced into the CAB flow as shown in the figure. Adjust the five air outlet ports to obtain the desired condition.
(C) "FRESH AIR INLET"
A Do not allow water to enter the fresh air port while washing the excavator. (A) "FRONT WINDOW" (B) "CHEST AREA" (C) "FOOT AREA" (D) "SIDE WINDOW" (E) "BACKWARD"
BAir Control Vent C Front air outlet The front air outlets can be independently adjusted as required. To defrost the windshield, rotate the outlets toward the windshield.
Position the inlet selector lever to the desired position.
(1) Front air outlet (1) Inlet selector lever (A) "FRESH AIR INLET" position (B) "INNER AIR RECIRCULATION" position
(A) "FRONT WINDOW" (B) "CLOSED" (C) "FOOT AREA"
