CHECKS BEFORE START
A The travel speed automatically changes into first speed (low speed) when the drive resistance increases while traveling second speed (high speed). Thereafter, when the resistance decreases, it returns to second speed. A If the tracks are clogged with sand or gravel while working on soft ground, lift up the track with the help of the boom, arm and bucket and dozer blade, and let the track rotate to remove the sand and gravel.
19
CAB TYPE MACHINES BWiper/Washer Switch To engage the wiper, turn on the switch for the wiper when the starter key is in the "RUN" position. A further push on the switch will activate the washer system. Even when the wiper switch is in the "OFF" position, the washer switch functions if it is pressed. A Do not activate the washer switch if the tank for the cleaning fluid is empty; the pump can be damaged. A Do not activate the wiper switch if the window is dry. In this case, make sure that cleaning fluid is applied to the pane before activating the wiper. A In frosty conditions, make sure that the wiper blade is not frozen to the glass before switching-on. The motor can be damaged if the wiper system is used under such conditions.
(A) "Rotate to remove sand and gravel"
A Do not push the dozer control lever into the float position as this will cause the machine to suddenly drop.
To avoid serious injury or death: A Do not work under the machine in this condition.
(1) Wiper switch
BInterior Lamp To turn on the interior lamp, set the interior lamp switch to the "ON" positions.
(1) Interior lamp (2) Interior lamp switch
(A) "ON" (B) "OFF"
