44
TIRES, WHEELS AND BALLAST
A Always attach tires as shown in the drawings. A If not attached as illustrated, transmission parts may be damaged.
BALLAST To avoid personal injury: A Additional ballast will be needed for transporting heavy implements. When the implement is raised, drive slowly over rough ground, regardless of how much ballast is used. A Do not fill the front wheels with liquid.
BFront Ballast Add weights if needed for stability and improving traction. Heavy pulling and heavy rear mounted implements tend to lift front wheels. Add enough ballast to maintain steering control and prevent tip over. Remove weight when no longer needed. (1) 145 to 150 N-m (14.8 to 15.3 kgf-m, 107.0 to 110.6 ft-lbs)
[Wheels with beveled or tapered holes] A Use the tapered side of lug nut.
C Front End Weights (option) The front end weights can be attached to the bumper. See your implement operator's manual for required number of weights or consult your local KUBOTA Dealer to use. A Besides the weight, a mounting kit is also required.
(1) Lug nut
[Wheels without beveled or tapered holes] A Use the flat side of the lug nut. Make sure to apply the spring washer.
(1) Front end weights (2) Bumper
A Do not overload tires. A Add no more weight than indicated in chart. Maximum weight
(1) Lug nut (2) Spring washer
25 kg x 3 pieces ( 165 lbs )
